Forging Laps and Folds: Causes, Detection and Prevention
A forging lap (also called a fold) is a surface or near-surface defect formed when metal folds over onto itself during forging and fails to weld together. It appears as a crack-like line, often following the contour of a fillet, rib or flash line. Laps are serious because they act as pre-existing cracks: under cyclic load they can initiate fatigue failure. They are caused mainly by poor material flow — incorrect preform design, sharp die radii, excess material, or incorrect forging sequence — and are prevented by good die design, forging simulation and controlled process parameters.
At a Glance: Laps and Folds
| Aspect | Summary |
| What it is | Metal folded over on itself without bonding |
Where it appears | Fillets, rib roots, corners, flash lines, step transitions |
| Main causes | Poor preform shape, sharp radii, excess stock, wrong sequence |
| Detection | Visual, MT, PT; UT for subsurface extension |
| Risk | Fatigue crack initiation, leak paths in pressure parts |
| Prevention | Die and preform design, simulation, lubrication, temperature control |
How Laps Form
During forging, metal flows to fill the die cavity. If material flows ahead of the rest and turns back on itself, or if two flow fronts meet at an angle, a fold is created. Because the surfaces are oxidised, they do not weld together, leaving a discontinuity. Common situations include:
- Upsetting a bar that is too slender, causing buckling
- A preform with too much material in one region, which buckles as it is compressed
- Sharp corners or small fillet radii in the die that force abrupt flow reversal
- Flash forming too early, trapping material that then folds back into the part
- Incorrect bite size or overlap in open die forging, creating step folds
Laps vs Other Forging Defects
| Defect | Distinguishing Feature |
| Lap / fold | Follows flow lines, oxidised faces, often at fillets |
Forging crack | Ragged, may branch; caused by low temperature or overstressing |
| Seam | Inherited from raw material, runs along bar length |
| Cold shut | Two flow fronts meeting without bonding (closely related to laps) |
How Laps Are Detected
- Visual inspection after descaling or shot blasting
- Magnetic particle testing (MT) for ferritic steels — highly sensitive to surface laps
- Liquid penetrant testing (PT) for stainless, nickel alloys and titanium
- Ultrasonic testing (UT) to judge depth where laps extend below the surface
- Macro-etch of sectioned parts during process qualification, showing grain flow folding
Can Laps Be Removed?
Shallow laps within machining allowance are often removed by machining or dressing, followed by re-inspection with MT or PT to confirm removal. Laps that extend below the finished surface, or appear on as-forged critical surfaces, normally cause rejection. Repair by welding is not acceptable for most critical forgings.
How Laps Are Prevented
- Preform and blocker design that distributes material correctly before finishing
- Generous fillet and corner radii in dies
- Forging simulation to predict flow and fold formation before cutting dies
- Correct stock volume to avoid excess material
- Controlled forging temperature and adequate lubrication
- Correct bite ratios in open die and radial forging
- First article macro-etch to verify flow
Why Laps Matter for Buyers
A lap in a fatigue-loaded shaft, landing gear part or pressure component can cause in-service failure. Buyers should require MT or PT on finished surfaces, define acceptance standards on the drawing, and ask suppliers how forging design and process controls prevent folds.
How Vinir Engineering Prevents Laps
- In-house die design and manufacturing, with preform optimisation
- Experience across open die, closed die, ring rolling and radial forging
- MT, PT and UT by qualified personnel in-house
- Macro-etch and grain flow verification during process qualification
- AS9100D across all four units, with NABL-accredited testing
